Industrial Power Semiconductor Module

Price 5964.0 INR/ Piece

Get a Price/Quote

MOQ : 10 Pieces

Industrial Power Semiconductor Module Specification

IP Rating
Not rated (depends on enclosure)

Output
Switched high voltage and current

Response Time
Fast switching (nanoseconds range) Hours

Components
IGBT

Features
Low saturation voltage, fast switching, high reliability, integrated protection diodes

Interface
Screw terminals for power, pins for control

Power Source
External DC link voltage

Usage
Industrial electrical devices, frequency converters, motor drives

Input
Control signal from gate circuit

Power Supply
External DC supply

Thermal Conductivity
High for efficient heat dissipation (with baseplate) Calorie (IT)/second/centimeter/°C

Operating Temperature
-40C to +150C Celsius (oC)

Product Type
IGBT Power Module

Application
Inverter systems, UPS, power supplies, motor control

Rated Voltage
1200V Volt (V)

Supply Voltage
1200V DC maximum Volt (v)

Size
Standard IGBT module size

Dimension (L*W*H)
Approx. 190mm x 90mm x 30mm Millimeter (mm)

Function
Switching and amplification in power electronics applications

Color
White

Weight
200 Grams (g)

Warranty
NA

Phase
3 PHASE

Thickness
Approx. 30 mm Millimeter (mm)

Capacity
600A Pcs/hr

Current Rating
600A

Frequency
Up to 20 kHz (switching frequency) Kilohertz ( KHZ )

Case Material
High-strength molded plastic with metal baseplate

Package Type
Power module

Reverse Recovery Time
Short (depends on diode used)

Insulation Voltage
2500V AC for 1 min

Configuration
Dual IGBT (half-bridge)

Mounting Type
Screw/bolt mount with insulated baseplate

Isolation Resistance
>100M

Internal Circuit
2 IGBTs and 2 freewheeling diodes

Collector Current (Ic)
600A

Collector-Emitter Voltage (Vce)
1200V

Gate Emitter Voltage (Vge)
+/-20V max

Industrial Power Semiconductor Module Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Week

Delivery Time
2 Days

Main Domestic Market
All India

About Industrial Power Semiconductor Module

The Electric 2MBI600VN-120-50 IGBT Power Module is a premium 1200V, 600A Dual IGBT (2-Pack) module engineered for high-power industrial applications. Built with 6th Generation V-Series technology, it offers fast switching, low switching losses, and excellent thermal performance. Its low-inductance module structure and copper baseplate improve efficiency and reliability, making it ideal for motor drives, industrial inverters, UPS systems, renewable energy converters, welding equipment, and heavy-duty automation systems. Designed for long-term operation in demanding environments, the 2MBI600VN-120-50 delivers dependable, high-efficiency power control for modern industrial applications.

High Power Handling and Fast Switching

With a collector-emitter voltage of 1200V and collector current of 600A, the 2MBI600VN-120-50 suits demanding applications such as industrial inverters and motor drives. This dual IGBT module supports switching frequencies up to 20kHz, ensuring precise and rapid response for power control requirements in automation and heavy machinery.

Durable and Safe Design

A reinforced insulation voltage of 2500V AC for 1 minute, robust high-strength plastic housing, and a metal baseplate ensure durability and operational safety. The module's insulated baseplate and high isolation resistance provide extra protection in high-voltage installations, making the device reliable for critical environments.

Efficient Installation and Thermal Management

The power module's screw/bolt mounting system and insulated baseplate allow for straightforward installation and enhanced heat dissipation. Its standard size and lightweight design (200 grams) make it adaptable to a wide range of power electronic systems, maintaining temperature within safe limits even during continuous operation.

FAQ's of 2MBI600VN-120-50 IGBT Power Module 1200V 600A Dual IGBT:

Q: How is the 2MBI600VN-120-50 IGBT Power Module typically used in industry?

A: This IGBT module is commonly implemented in inverter systems, frequency converters, UPS, and motor drives to manage high-voltage, high-current switching tasks. Its fast switching speed and robust construction make it ideal for heavy-duty industrial electrical applications.

Q: What mounting method is recommended for this power module?

A: The module is designed for screw or bolt mounting using its insulated baseplate. This ensures secure mechanical fixation and optimal electrical isolation, which are important for reliable, long-term operation in power electronics enclosures.

Q: When should I consider using the 2MBI600VN-120-50 in my system?

A: Consider this power module when your application requires switching or amplification of voltages up to 1200V and currents up to 600A, especially in systems that demand high reliability and efficient thermal management, such as motor control or large uninterruptible power supplies.

Q: Where does the module connect within a power electronics circuit?

A: The 2MBI600VN-120-50 is integrated into the power stage of a circuit. Power connections are made through screw terminals, while control signals are input via dedicated pins. It typically connects between the DC link supply and load to facilitate high-voltage, high-current switching operations.

Q: What process ensures reliable thermal management for this module?

A: The high thermal conductivity of the baseplate, combined with the option to mount the module onto a heat sink, allows for effective dissipation of heat. This process is essential to maintain operational stability and longevity, especially under continuous high-load conditions.

Q: How does using this IGBT module benefit my power electronic application?

A: It allows for efficient switching and amplification at high voltages and currents, leads to reduced losses due to its low saturation voltage, and offers integrated freewheeling diodes for additional protection. This results in improved system efficiency, reliability, and longer operational life.

2MBI600VN-120-50, 2MBI600 IGBT, 600A IGBT, 1200V IGBT, IGBT Power Module, High Power IGBT Module, Industrial IGBT, Power Semiconductor Module, High Voltage IGBT, Heavy Duty IGBT, IGBT Switching Module, Inverter IGBT, Motor Drive IGBT, Industrial Power Module
