MOSFET Electronic Component

Price 10.0 INR/ Piece

Get a Price/Quote

MOQ : 100 Pieces

MOSFET Electronic Component Specification

Response Time
Fast Transient Response

Input
7V to 35V DC

Operating Temperature
0C to +125C

Output
5V DC, Regulated

Power Source
DC Input

Thermal Conductivity
Standard TO-220 heatsinkable

Components
7805 Voltage Regulator IC

Features
Short-circuit protection, Thermal shutdown, Overload protection

Usage
Voltage Regulation in Electronic Circuits

IP Rating
Not Rated

Interface
Through-hole, 3-pin

Power Supply
DC

Product Type
Linear Voltage Regulator IC

Application
Embedded Systems, Microcontroller Circuits, Power Adapters

Rated Voltage
5V DC Output

Supply Voltage
7V to 35V DC

Size
TO-220 Package

Dimension (L*W*H)
10 mm x 8 mm x 16 mm (excluding pins)

Function
Positive Voltage Regulation

Color
Black/Silver (Metal Tab)

Weight
~2 g

Capacity
1.5A Output Current

Current Rating
1.5A Max Output Current

Thickness
Approx. 4 mm (body)

Frequency
N/A (DC component)

Storage Temperature Range
-65C to +150C

Maximum Dissipation
15W (with heatsink)

Lead Temperature (Soldering, 10s)
+230C

Load Regulation
0.1% typ.

Mounting Type
Through Hole (TO-220)

Dropout Voltage
2V Typical at 1A

Line Regulation
0.01%/V typ.

Pin Configuration
Pin 1: Input, Pin 2: Ground, Pin 3: Output

Noise Rejection
Typical 55dB

Case Material
Molded Plastic with Metal Tab

MOSFET Electronic Component Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
2 Days

Main Domestic Market
All India

About MOSFET Electronic Component

The 7805 5V Voltage Regulator IC is a widely used three-terminal positive linear regulator designed to provide a stable 5V DC output from a higher DC input voltage. It is commonly used in electronic power-supply circuits where a regulated 5V supply is required.

The regulator converts excess input voltage into heat while maintaining the required regulated output voltage. For example, when supplied with a suitable input above 5V, the 7805 provides a regulated 5V output for compatible electronic circuits.

The TO-220 version features three terminals for simple through-hole PCB mounting. The standard pin configuration is Input, Ground and Output, making the component easy to integrate into conventional power-supply designs.

The 7805 family incorporates protection features such as internal current limiting, thermal overload protection and safe-area protection, helping protect the regulator during overload and excessive-temperature conditions.

Key Features

Fixed 5V DC regulated output
Positive linear voltage regulator
3-pin TO-220 package
Through-hole mounting
High-quality voltage regulation
Internal thermal overload protection
Short-circuit/current-limiting protection
Suitable for power-supply circuits
Simple Input-GND-Output connection
Widely used electronic component
Suitable for PCB repair and replacement
Available in different manufacturer versions

Applications

Electronic power supplies
5V DC power supply circuits
Microcontroller circuits
Digital electronic circuits
Sensor circuits
Embedded systems
Industrial control boards
PCB repair and maintenance
LED and display circuits
Communication equipment
Audio and electronic equipment
General-purpose voltage regulation
