IGBT Semiconductor Module Specification

Input
DC

Usage
Industrial Power Electronics

Power Supply
Electrical

Components
IGBT MODULE

Features
High Voltage, High Current, Reliable Switching

Power Rating
High Power

Product Type
IGBT Power Module

Application
Inverter, Motor Drive, Power Conversion

Supply Voltage
1200 V Volt (v)

Size
Approx. 94 38 mm

Dimension (L*W*H)
Approx. 94 38 30 mm Millimeter (mm)

Function
Power Switching

Color
Black

Weight
150 Grams (g)

Warranty
NA

Rated Voltage
1200 V Volt (V)

Usage & Applications
Inverter, Motor Drive, UPS, Industrial Equipment

Phase
3

Rated Current
50 Ampere (amp)

Material
Semiconductor / Metal

Capacity
50A m3/hr

Current Rating
50A

Frequency
50/60 Hz Hertz (HZ)

IGBT Semiconductor Module Trade Information

Minimum Order Quantity
10 Pieces

Payment Terms
Cash Advance (CA)

Supply Ability
100 Pieces Per Week

Delivery Time
2 Days

Main Domestic Market
All India

About IGBT Semiconductor Module

The 7MBR50SB120H-70 is a high-performance Intelligent Power Module (IPM) manufactured by Fuji Electric. It is designed for high-efficiency motor control and power conversion applications. This module integrates IGBTs, free-wheel diodes, gate drive circuitry, and protection functions into a compact package, making it an ideal solution for industrial inverter systems and motor drives.

Designed with advanced IGBT technology, the module offers low power loss, high switching speed, excellent thermal performance, and long operational life. It is widely used in industrial automation, HVAC systems, CNC machines, servo drives, UPS systems, and renewable energy equipment.

Key Features

1200 V rated voltage
50 A rated current
3-phase IGBT power module
High-power switching capability
Suitable for inverter applications
Suitable for motor-control systems
Compact industrial power-module design
Reliable power conversion performance
Suitable for industrial equipment repair and replacement

7MBR50SB120H-70, 7MBR50 IGBT, Fuji IGBT Module, IGBT Power Module, 1200V IGBT, 50A IGBT, High Power IGBT, Industrial IGBT Module, Power Semiconductor Module, IGBT Module, Electronic IGBT Module, Inverter IGBT, Motor Drive IGBT
