Mitsubishi Electric PS21767H35CE2 Intelligent Power Module (IPM)

About Mitsubishi Electric PS21767H35CE2 Intelligent Power Module (IPM)

The Mitsubishi Electric PS21767H35CE2 is a high-performance 600V, 30A Intelligent Power Module developed for compact three-phase inverter systems. It combines six CSTBT IGBTs, gate-drive circuitry, and built-in protection features in a single insulated Mini DIP package. This integration reduces the number of external components, simplifies circuit design, and enhances overall system reliability.

The module supports 3V and 5V control logic and includes essential protection features such as under-voltage lockout, short-circuit protection, and fault output, helping safeguard both the power stage and connected motor. It is widely used in air conditioners, washing machines, refrigerators, industrial motor drives, HVAC systems, CNC equipment, and other inverter-based applications where efficient, reliable motor control is required.
