Infineon FP25R12KE3 1200V 25A EconoPIM 2 Three Phase IGBT Module with NTC

Infineon FP25R12KE3 1200V 25A EconoPIM 2 Three Phase IGBT Module with NTC About

The Infineon FP25R12KE3 is a 1200V, 25A IGBT power module designed for high-performance power switching and three-phase inverter applications. It is part of Infineon's IGBT module family and is intended for demanding industrial power-electronics applications.

The module combines IGBT switching technology with free-wheeling diode structures to provide controlled switching of high-voltage DC power into AC or other controlled power waveforms. Its 1200V voltage rating provides a suitable margin for many high-voltage inverter and motor-drive applications, while the 25A current rating makes it suitable for medium-power switching systems.

The FP25R12KE3 is particularly suitable for three-phase motor drives, variable-frequency drives (VFDs), industrial inverters, UPS equipment, power conversion systems and automation equipment.

For reliable operation, the module should be installed with suitable gate-driver circuitry, electrical protection and thermal management. A properly sized heat sink is important because IGBT switching and conduction losses generate heat during operation.

Key Features

• 1200V collector-emitter voltage rating
• 25A collector current class
• Infineon IGBT module
• IGBT3 technology
• Three-phase inverter configuration
• Integrated free-wheeling diode structure
• High-voltage switching capability
• Suitable for motor-drive applications
• Designed for industrial power electronics
• Requires appropriate heat dissipation

Applications

• 3-Phase Inverters
• AC Motor Drives
• Variable Frequency Drives (VFD)
• Industrial Automation
• UPS Systems
• Power Conversion Equipment
• Industrial Motor Controllers
• Welding Equipment
• Renewable-Energy Inverters
• Industrial Power Supplies
• High-Voltage Switching Systems
